60gsm 90gsm 200gsm 240gsm 400gsm Aramid Fiber Fabric
Products
Products Categories
Featured Products

60gsm 90gsm 200gsm 240gsm 400gsm Aramid Fiber Fabric

Aramid fiber is a new type of high-tech synthetic fiber with excellent properties such as ultra-high strength, high modulus and high temperature resistance, acid and alkali resistance, light weight, etc. Its strength is 5-6 times that of steel wire, and the modulus is steel wire or 2 to 3 times of glass fiber, the toughness is twice that of steel wire, and the weight is only about 1/5 of the wire. At 560 degrees, it does not decompose and does not melt. It has good insulation and aging resistance and has a long life cycle.

Aramid fiber cloth is a strong and durable synthetic fabric made from aramid fibers. It has a high strength-to-weight ratio, making it a popular choice for applications where strength is required without adding weight. It is commonly used in protective clothing, body armor, sports equipment, and the aerospace and automotive industries due to its resistance to abrasion, cut, impact, and heat.

  • Min.Order: 10 square meters
  • Materia: Aramid fiber
  • Payment Type: T/T,Paypal,Credit card, L/C,Western Union
  • Transportation: Ocean, Land, Air, Express
  • Port: Shanghai, Guangdong, Qingdao

Product Feature


1. High strength-to-weight ratio: Extremely strong and durable

2. Heat resistance: (1) Can withstand temperatures up to 370°C (698°F) without significant degradation; (2) Excellent thermal insulation properties

3. Chemical resistance: Good resistance to alkalis and salt solutions

4. Flexibility: Can be woven into various forms while maintaining strength


Product Parameter


Name

Aramid fiber fabric

Material

100% aramid fiber

Width

100cm or customized

Weave/warp

Twill or plain

FAW

60~450 gsm

Thickness

0.08-0.5mm

Color

Yellow or customized


Application Field


Aramid fibers are a class of heat-resistant and strong synthetic fibers. With high strength, high modulus, flame resistance, strong toughness, good insulation, corrosion resistance and good weaving property, they’re mainly used in bicycle tires, marine cordage, marine hull reinforcement, extra cut proof clothes, parachute, cords, rowing, kayaking, snowboarding, packing, conveyor belt, sewing thread, gloves, audio, fiber enhancements, as an asbestos substitute and various security areas.


Application Field
Application Field 2
Application Field 3

Application Field 4
Application Field 5
Application Field 6

Application Field 7
Application Field 8
Application Field 9

Why Choose Us?


why choose us

Buyer Review


buyers review

Our Factory



company1
Our Factory

Our Factory 1
Our Factory 2
Our Factory 3
Our Factory 4

Packing & Transportation


packing

FAQ




Product Parameter


Code    No. Style Width Density(10m/m) Thickness  Weight Length Re-mark
m/m Warp Fill m/m  g/m² m
FZ-af-6001 Plain 1000  13  13  0.08    60  100  200d
FZ-af-6002 Plain 1000  20  20  0.12    90  100  200d
FZ-af-6003 Plain 1000  13  13  0.16    120  100  400d
FZ-af-6004 Plain 1000  11  11  0.16    120  100  500d
FZ-af-6005 Plain 1000  0.20    154  100  1000d
FZ-af-6006 Plain 1000  0.22    178  100  1000d
FZ-af-6007 Plain 1000  0.24    200  100  1000d
FZ-af-6008 Plain 1000  5.5  5.5  0.23    185  100  1000d
FZ-af-6009 Plain 1000  0.24    200  100  1500d
FZ-af-6010 Plain 1000  0.26    235  100  1500d
FZ-af-6011 Plain 1000  8.8  0.34    300  100  1500d
FZ-af-6012 Plain 1000  4.5  4.5  0.35    305  100  3000d
FZ-af-6013 Plain 1000  5.8  0.50    400  50  3000d
FZ-af-6014 Twill 1000  11.5  11.5  0.51    410  50  1500d
FZ-af-6015 Twill 1000  5.8  0.50    400  50  3000d
FZ-af-6016 Plain 1000  6.5  6.5  0.26    240  100  1500d
FZ-af-6017 UD 500  5.8  0.13    200  100  3000d
FZ-af-6018 UD 500  0.19    280  100  3000d
FZ-af-6019 UD 500  0.28    415  50  6000d
