High Modulus Reinforcement UD Carbon Fiber Tape For Building Repair

UD carbon fiber tape has high strength, low density, thin thickness, and basically does not increase the self weight and cross-sectional size of reinforced components.The construction process of UD carbon fiber tape is relatively simple, and it can be used together with matching resins and adhesives to form a complete carbon fiber composite material system. This construction method is not only convenient and fast, but also can effectively improve the efficiency of reinforcement and repair work.

  • Min.Order: 50 square meters
  • Style: UD
  • Color: Black
  • Payment Type: T/T,Paypal,Credit card,L/C,Western Union
  • Transportation: Ocean,Land,Air,Express
  • Port: Shanghai,Guangdong,Qingdao

Product Feature


1. The fibers run parallel to each other in one direction, with no fibers crossing them.

2. Provides excellent tensile strength in the direction of the fibers.

3. High strength-to-weight ratio

4. Excellent stiffness

5. Corrosion resistance

6. Aesthetic appearance

Product  Information

Product Type

UD Carbon Fiber Fabric

Material

100% carbon fiber

Fabric Type

Cloth

Warp

12k

FAW

200~300g/m2 or customized

Thickness

0.111~0.167mm

Color

Black

Width

50cm or customized


More Choice


More Choice

Application Field


In the field of architecture, UD carbon fiber fabric plays an important role in building reinforcement. It can be adhered to the structure in need of reinforcement along the tensile direction using epoxy resin adhesive, thereby forming a new composite and increasing the strength and stiffness of the structure. This material is lightweight and high-strength, and will not increase the weight of the building. It is particularly suitable for the reinforcement and repair of old buildings, which can improve the seismic and wind resistance of the building and extend its service life.


Application Field
Application Field 2
buiilding-1
Application Field 3

Why Choose Us?


why choose us-1

Buyer Review


buyer review

Our Factory



company1
company2

bu-1
bu-2
bu-3
bu-4

Packing & Transportation


packing

FAQ




Product Parameter


Technical parameters of carbon fiber unidirectional fabric

Specification

Surface density

200 g/ m2

300 g/ m2

200 g/ m2

300 g/ m2

Theoretical thickness

0.111 mm

0.167 mm

0.111 mm

0.167 mm

Tensile strength

≥3400 MPa

≥3400 MPa

≥3000 MPa

≥3000 MPa

Elastic modulus

≥240 GPa

≥240 GPa

≥210 GPa

≥210 GPa

Breaking elongation

≥1.7%

≥1.7%

≥1.5%

≥1.5%
