High Strength 12k 300g Unidirectional Carbon Fabric

Carbon fiber unidirectional fabric is a high-performance composite material woven from unidirectional carbon fiber filaments through specific processes. Its characteristic is that carbon fiber filaments are arranged only in one direction, usually in the warp or weft direction of the fabric, which makes carbon fiber unidirectional fabric have very high strength and stiffness in a specific direction, and can withstand a large amount of tensile and compressive forces.

With the continuous progress of science and technology and the rapid development of the carbon fiber cloth industry, the production process of unidirectional carbon fiber cloth is constantly improving, the performance is constantly improving, and the cost is constantly decreasing. In the future, unidirectional cloth is expected to be applied in more fields, such as new energy, environmental protection, etc. At the same time, with the continuous improvement of people's requirements for material performance, the research and innovation of unidirectional cloth will also be continuously promoted to meet the new demands and challenges of the market.

  • Min.Order: 50 square meters
  • Style: UD
  • Color: Black
  • Payment Type: T/T,Paypal,Credit card,L/C,Western Union
  • Transportation: Ocean,Land,Air,Express
  • Port: Shanghai,Guangdong,Qingdao

Product Feature


1.It has very high strength and stiffness, and can withstand a large amount of tensile and compressive forces.
2.Unidirectional fiber arrangement can give carbon fiber cloth excellent performance in specific directions.
3.It can be stacked in different directions as needed to meet different engineering requirements.

Product  Information

Product Type

UD Carbon Fiber Fabric

Material

100% carbon fiber

Fabric Type

Cloth

Warp

12k

FAW

300g/m2

Thickness

0.167mm

Color

Black

Width

100cm or customized


More Choice


More Choice

Application Field


Carbon fiber unidirectional cloth is a high-performance fiber composite material that is widely used in various industries due to its unique mechanical properties and processing convenience.In the field of civil engineering, unidirectional carbon fiber cloth plays an important role in structural reinforcement. By pasting it onto the surface of concrete components, the tensile, shear, and compressive strength of the components can be significantly improved, thereby enhancing the stability and load-bearing ability of the entire structure. This application method is particularly suitable for structural safety assessment and improvement of key engineering parts such as bridges and high-rise buildings.


Application Field
Application Field 2
buiilding-1
Application Field 3

Why Choose Us?


why choose us-1

Buyer Review


buyer review

Our Factory



company1
company2

bu-1
bu-2
bu-3
bu-4

Packing & Transportation


packing

FAQ




Product Parameter


Technical parameters of carbon fiber unidirectional fabric

Specification

Surface density

200 g/ m2

300 g/ m2

200 g/ m2

300 g/ m2

Theoretical thickness

0.111 mm

0.167 mm

0.111 mm

0.167 mm

Tensile strength

≥3400 MPa

≥3400 MPa

≥3000 MPa

≥3000 MPa

Elastic modulus

≥240 GPa

≥240 GPa

≥210 GPa

≥210 GPa

Breaking elongation

≥1.7%

≥1.7%

≥1.5%

≥1.5%
