Hot Selling 12K 200g 300g 400g 600g UD Carbon Fiber Fabric

Carbon fiber unidirectional fabric is a high-performance composite material woven from unidirectional carbon fiber filaments through specific processes. This material has very high strength and stiffness in specific directions, and can withstand a large amount of tensile and compressive forces. The fiber arrangement of unidirectional carbon fiber cloth is usually only in one direction, usually the warp or weft direction, which makes its performance particularly outstanding in that direction.
The main characteristic of carbon fiber unidirectional fabric is the singularity of fiber direction, which has the advantages of high strength, high modulus, lightweight, etc. It is widely used in aerospace, automotive industry, sports equipment and other fields.

  • Min.Order: 50 square meters
  • Style: UD
  • Color: Black
  • Payment Type: T/T,Paypal,Credit card,L/C,Western Union
  • Transportation: Ocean,Land,Air,Express
  • Port: Shanghai,Guangdong,Qingdao

Product Feature


High strength and high stiffness: Due to the unidirectional arrangement of carbon fiber filaments, carbon fiber UD cloth has very high strength and stiffness in the fiber direction, and can withstand a large amount of tensile and compressive forces.

Lightweight: Carbon fiber UD fabric is relatively lightweight, but its strength is very high, which makes it widely used in aerospace, automotive industry and other fields, effectively reducing product weight and improving fuel efficiency.

Corrosion resistance and fatigue resistance: Carbon fiber UD fabric has excellent corrosion resistance and fatigue resistance, and can maintain stable working conditions for a long time in harsh environments.

Convenient construction: The construction process of carbon fiber UD cloth is relatively simple, and it can be used together with matching resins and adhesives to form a complete carbon fiber composite material system, which is convenient, fast, and can effectively improve the efficiency of reinforcement and repair work.

Product  Information

Product Type

UD Carbon Fiber Fabric

Material

100% carbon fiber

Fabric Type

Cloth

Warp

12k

FAW

200~300g/m2 or customized

Thickness

0.111~0.167mm

Color

Black

Width

100cm or customized


More Choice


More Choice

Application Field


1.Concrete surface preparation, crack repair, leak stop, get rid of the aged, loose concrete part
2.Brush primer (0.2-0.4kg/m2)
3. Base surface preparation( putty 1.0-1.5kg/m2)
4. Brush epoxy resin on the surface(0.4-0.5kg/m2)
5. Stick the carbon fiber fabric onto structure
6. Saturate the fabric by brushing epoxy resin along the fabric, ensure that there is no bubble existing in the composite matrix(very crucial) 0.1-0.2kg/m2
7. If more following carbon fiber fabric layer, brush 4-6times each layer
8. Keep the structure from any impact during the following 24hrs


Application Field
Application Field 2
buiilding-1
Application Field 3

Why Choose Us?


why choose us-1

Buyer Review


buyer review

Our Factory



company1
company2

bu-1
bu-2
bu-3
bu-4

Packing & Transportation


packing

FAQ




Product Parameter


Technical parameters of carbon fiber unidirectional fabric

Specification

Surface density

200 g/ m2

300 g/ m2

200 g/ m2

300 g/ m2

Theoretical thickness

0.111 mm

0.167 mm

0.111 mm

0.167 mm

Tensile strength

≥3400 MPa

≥3400 MPa

≥3000 MPa

≥3000 MPa

Elastic modulus

≥240 GPa

≥240 GPa

≥210 GPa

≥210 GPa

Breaking elongation

≥1.7%

≥1.7%

≥1.5%

≥1.5%
